Forklift Gear Charging Pump 30B-13-11200 30B-13-11201 – FD-G20-30 16-17
$33.99
Forklift charging pump 30B-13-11200 / 30B-13-11201 / YQXF30 for FD-G20 G25 G30 16-17 series powershift transmissions. Cast iron gear pump, OEM replacement.
Forklift Charging Pump 30B-13-11200 / YQXF30 — FD-G20-30 Series Powershift Transmission
The 30B-13-11200 (also cross-referenced as YQXF30) is a gear-type charging pump for FD-G20, FD-G25, FD-G30, and 16-17 series forklift powershift transmissions. This cast iron pump is driven directly from the transmission input shaft and supplies pressurized hydraulic oil for three critical functions: clutch pack engagement pressure, gear train lubrication, and torque converter feed. Without a functional charging pump, the transmission has zero hydraulic pressure — no clutch engagement, no lubrication, and immediate transmission damage upon engine start. The 30B-13-11200 is a direct bolt-on OEM replacement and does not require adapter plates or hydraulic circuit modifications.
This pump fits forklifts in the 2-3 ton capacity range equipped with FD-G20, G25, G30 and 16-17 series powershift transmissions. The YQXF30 designation indicates compatibility with the YQXF-series transmission control system commonly found on TCM, Komatsu, and Chinese-brand forklifts. The pump’s cast iron housing provides durability under continuous high-pressure operation, and the gear-type design delivers consistent flow rate across the full engine RPM range. Common failure signs include: complete loss of forward and reverse drive (pump failure, zero system pressure); transmission overheating within 10-15 minutes of operation (insufficient fluid circulation through the cooler); whining noise from the transmission pump cavity (worn gear teeth or cavitation); slow or delayed clutch engagement (worn pump cannot build pressure quickly); and metal debris in the transmission filter (pump gear or housing material wear).
Installation requires draining the transmission, removing the access cover or pan to reach the pump, and replacing the pump as a complete assembly. The pump drive coupling must be inspected for wear — a damaged coupling transfers vibration to the new pump and causes premature gear wear. Always pre-fill the pump cavity with clean transmission fluid and replace the mounting gasket or O-ring. Flush the transmission cooler circuit and replace the filter during this service. Bracketed to the transmission case with standard bolt pattern — no special tools required beyond standard metric wrenches. For related transmission components, browse our Forklift Hydraulic Transmission Parts catalog.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 30B-13-11200 / 30B-13-11201 / YQXF30 |
| SKU | SP100306 |
| Type | Gear-Type Charging Pump |
| Material | Cast Iron |
| Application | FD-G20 / G25 / G30, 16-17 Series |
| Function | Clutch Pressure + Lubrication + Torque Converter Feed |
Compatible Forklift Models
| Brand | Models |
|---|---|
| TCM / Komatsu / Multi-brand | FD-G20, FD-G25, FD-G30, 16-17 series forklifts with powershift transmission |
Each pump is packaged in a neutral export box with protective padding. Express shipping via DHL/UPS/FedEx to worldwide destinations. For compatibility verification or bulk orders, contact our team with your transmission model.
Full Category Coverage
One supplier for all forklift systems — engine, hydraulic, electrical, mast, brake, undercarriage. No need to juggle multiple vendors.
No Minimum Order
Trial orders welcome. Single-piece to bulk supply. You test first, scale later. We treat every order seriously.
Three Quality Choices
Original, OEM, or Aftermarket. You decide based on budget and application. We don't upsell — you control cost and performance.
Direct 1-on-1 Communication
You talk to the sourcing decision maker. No sales reps, no forwarding. Faster answers, clearer quotes, real accountability.
Mixed Order Consolidation
Combine different parts in one shipment. Save on freight. We handle the picking, packing, and export documentation.
After-Sale Warranty
Manufacturing defects covered. Free replacement or credit arranged quickly. Your trust is worth more than any single transaction.
Same part, different brand numbers. This cross-reference table helps you confirm compatibility across multiple forklift brands. If your brand or part number is not listed, send it to us — we will match it.
| Brand | OEM Part Number | Notes |
|---|---|---|
| TOYOTA | 47201-23300 | Original |
| KOMATSU | 3EB-30-41200 | Original |
| HELI | 24022-83011 | Original |
| HANGCHA | R240-83011 | Original / OEM |
| LINDE | 0009830123 | OEM |
| HYSTER | H47201-233 | OEM |
| TCM | TCM-47201 | OEM |
| AFTERMARKET | AM-47201 | Cost-effective replacement |
