Forklift Parts NC9717-740100-000 Headlamp Switch for CPCD30

HELI NC9717-740100-000 Headlamp Switch for CPCD30 Forklift

The NC9717-740100-000 is an OEM dash-mounted 3-position rocker switch controlling front headlight and rear work light circuits on HELI CPCD30 diesel forklifts. Positions are OFF (all lights disconnected), PARK (front marker lights and rear tail lights for stationary visibility at loading docks), and HEADLAMP (main forward headlights for travel illumination). The PARK position is critical when idling at a dock at dusk — marker lights provide visibility to truck drivers without full headlight glare reflecting off trailers and blinding the driver during docking.

The snap-action rocker mechanism uses silver-plated contacts rated 12V-24V DC at 10A continuous. The body is glass-filled nylon with UV stabilizers to prevent yellowing from windshield-transmitted sunlight. A melted or distorted switch housing indicates an overload condition — typically from a shorted headlight bulb drawing excessive current. Forklift directional switch category.

Technical Specifications

• OEM: NC9717-740100-000 (HELI)
• Type: 3-position rocker headlight switch
• Positions: OFF-PARK-HEADLAMP
• Rating: 12V-24V DC, 10A
• Contacts: Silver-plated snap-action
• Body: Glass-filled nylon, UV-stabilized
• Fitment: HELI CPCD30 dash panel

If the switch housing shows any sign of melting, replace the switch AND verify the headlight circuit fuse rating before re-energizing. Baldwin Filters. Worldwide shipping from Kingstream.
