Self-Locking Handbrake Assembly for 5-10 Ton Forklifts

This self-locking handbrake assembly is designed as a direct OEM replacement for 5-10 ton internal combustion counterbalance forklifts, providing reliable mechanical parking brake engagement through a ratcheting self-lock mechanism that holds the brake shoes firmly against the drums without relying on hydraulic pressure. The assembly includes the handbrake lever with ergonomic grip handle, ratchet pawl and sector gear for positive locking at any pull position, release button with return spring, mounting bracket, pivot pin, and linkage cable attachment clevis. The self-locking design ensures the parking brake remains securely engaged even when the forklift is parked on inclines, during loading/unloading operations, or when left unattended for extended periods.

The handbrake lever is fabricated from heavy-gauge pressed steel with a durable black powder-coat finish that resists corrosion in humid, dusty, and chemically exposed industrial environments. The ratchet teeth are induction-hardened for wear resistance, maintaining crisp locking engagement through tens of thousands of application cycles. The release button assembly uses a chrome-plated steel push rod with a compression return spring that requires intentional thumb pressure to release, preventing accidental disengagement from vibration or inadvertent contact. The pivot mechanism features a hardened steel bushing and grease fitting for long-term lubrication access.

Compatible with HELI K50-K70, Hangcha K50-K70, Lonking K Series, and other domestic-brand 5-10 ton forklifts using mechanical handbrake/cable-actuated parking brake systems. Before installation, verify the mounting bracket bolt pattern and cable attachment dimensions match your existing unit. Lubricate the pivot points and ratchet mechanism with heavy-duty chassis grease during installation, and adjust the cable tension per the forklift service manual to achieve full brake engagement at 3-5 clicks of the ratchet. For compatible handbrake cables, brake shoes, and complete parking brake overhaul kits, visit our Forklift Brake Parts section.

Technical Specifications

• SKU: HANDBRAKE-5-10T
• Capacity: 5.0 – 10.0 Ton Forklift
• Type: Self-Locking / Ratcheting Handbrake
• Lever Material: Pressed Steel, Black Powder-Coat
• Ratchet: Induction-Hardened Steel Teeth
• Release: Chrome-Plated Push Button with Return Spring
• Includes: Lever, Ratchet Assembly, Mounting Bracket, Clevis

Compatible Forklift Models

Each handbrake assembly is tested for ratchet engagement force, release mechanism function, and lever travel range before packaging. The assembly ships pre-lubricated with mounting bolts included, packed in a foam-lined box with VCI anti-corrosion protection. 12-month warranty. Installation tip: after mounting, pull the handbrake to full engagement and verify the warning light switch (if equipped) activates correctly. For handbrake cables, return springs, and related parking brake components, contact our team.
