Forklift Parts Pedal Pad N163-430001-000

HELI Pedal Pad N163-430001-000 — OEM Accelerator & Brake Pedal Cover for CPCD/CPD Forklift

The HELI pedal pad N163-430001-000 is an OEM molded rubber pedal cover designed for the accelerator and brake pedal arms on HELI CPCD (diesel/LPG) and CPD (electric) series counterbalance forklifts from 1T to 3.5T capacity. The pedal pad is a component that operators interact with more than any other control surface on the forklift — the right foot pivots between accelerator and brake pedals 200-400 times per shift, with each pivot applying concentrated heel pressure to a contact patch roughly 30mm in diameter on the pad surface. When the original pedal pad wears through its full 2.5mm tread depth at the heel pivot point — typically after 6,000-10,000 operating hours — the remaining smooth EPDM surface has zero wet-traction capability, and the operator boot sole can slip off the brake pedal during a panic stop. At 10 km/h travel speed on a wet concrete warehouse floor, a 0.5-second foot-slip delay in brake pedal engagement translates to 1.4 meters of additional stopping distance — the difference between stopping short of a racking column and impacting it with a loaded pallet.

The N163-430001-000 pedal pad is molded from high-density EPDM (ethylene propylene diene monomer) rubber — selected for its combination of wet and dry coefficient of friction, resistance to permanent compression set under sustained pedal pressure, and immunity to the diesel fuel drips and hydraulic oil spray that cause PVC and natural rubber pedal pads to swell and soften within months of installation. The tread face features a deep 2mm diamond-crosshatch anti-slip pattern with lateral water-evacuation channels that displace moisture from the boot-pad interface — a critical design feature absent on economy pads that use only surface texture without drainage channels, allowing water to hydroplane between boot sole and pad surface. The pad underside uses a precision-molded rib pattern that mates with the HELI steel pedal arm profile, providing a snap-fit mechanical lock that eliminates the need for adhesive — the pad stays securely in place through thermal expansion cycles from -30°C cold-start winter operations to +60°C engine bay radiant heating during summer multi-shift operations, without the adhesive degradation that causes glue-mounted pads to curl and peel at the edges.

Direct OEM replacement for HELI part number N163-430001-000. Fits accelerator and brake pedal arms on HELI CPCD10 through CPCD35 diesel/LPG H2000 and A-series, and CPD10 through CPD35 electric forklifts. Installation requires no tools — remove the worn pad by pulling upward from the heel edge, align the new pad with the pedal arm, and press firmly around all edges until all rib interlocks engage with an audible click. For matching cab floor mats, engine cover mats, and heel pads, browse our forklift floor mat category.

Technical Specifications

• OEM / Part Number: N163-430001-000 (HELI)
• Type: Molded rubber pedal pad cover — accelerator and brake pedal
• Material: High-density EPDM rubber
• Tread Depth: 2mm diamond-crosshatch pattern with water-evacuation channels
• Pad Thickness: 2.5mm nominal at center, 3mm at heel zone
• Installation Method: Snap-fit mechanical lock, precision-molded rib interlock — no adhesive
• Temperature Range: -30°C to +60°C, no adhesive degradation
• Chemical Resistance: Diesel fuel, hydraulic oil, battery acid mist
• Fitment: HELI CPCD10-CPCD35 H2000/A-series, CPD10-CPD35 electric
• Service Life: 6,000-10,000 operating hours in normal use
• Installation: Tool-free — pull off old pad, press on new pad until audible click

Compatible HELI Forklift Models

Each HELI pedal pad N163-430001-000 ships individually in protective packaging. Before installation, clean the bare steel pedal arm with a wire brush to remove any rust scale or adhesive residue from a previously glue-mounted aftermarket pad — rust scale prevents the rib interlock from fully seating, and adhesive residue acts as a lubricant that allows the pad to slide off under lateral foot pressure. After pressing the pad onto the pedal arm, verify full engagement by attempting to pull the pad upward at all four corners — any corner that lifts more than 1mm indicates the rib is not fully seated in the pedal arm groove and must be pressed again. Inspect the tread depth at the heel pivot point during each engine oil change (250-hour interval): when the diamond-crosshatch pattern is worn smooth and the wear indicator dimples are no longer visible in the heel zone — typically after 1mm of tread wear from the original 2mm — the pad has reached its replacement threshold and should be changed before the remaining 1mm wears through during the next service interval. Never operate the forklift with a missing pedal pad — bare steel pedal arms have a coefficient of friction approaching zero when wet, creating an immediate operator safety hazard. For forklift operator safety equipment guidelines, consult Baldwin Filters. Kingstream stocks HELI N163-430001-000 pedal pads for same-day dispatch — worldwide shipping with online tracking.
