Tractor Steel Wheel Rim 5.5F-16 – 750-16 6-Hole
$22.00
5.5F-16 steel farm tractor wheel rim for Kubota Iseki Yanmar compact utility tractors. Adjustable track width, lug-bolt mounting, structural steel. Fits 7.50-16 agricultural tires front and rear positions.
Tractor Steel Wheel Rim 5.5F-16 — 750-16 Tire 6-Hole Steel Wheel Rim for Farm Tractors & Kubota
This tractor steel wheel rim size 5.5F-16 is a Kingstream OEM steel wheel rim for 750-16 tires on farm tractors, Kubota tractors, and agricultural machinery. The 5.5F-16 rim is a 16-inch diameter, 5.5-inch width steel wheel with 6-hole bolt pattern — a standard agricultural rim used on the front and rear axles with adjustable track width for row-crop farming operations. Available in multiple PCD configurations: 152mm (6×19mm holes), 180mm (6×17mm holes), and 140mm (6×20.5mm holes). Center bore diameters: 117.7mm, 141mm, and 107mm. Offset options: 0mm and 36mm. Disc thickness: 8mm. Width range: 8-10 inches. Steel construction with white or gray stoving varnish finish. ISO9001 certified. 20kg. 1-year warranty. Kingstream OEM quality for agricultural machinery operators.
INSTALLATION PROCEDURE: Step 1 — Safely support the tractor with jack stands. Remove wheel nuts and pull the old wheel assembly. Step 2 — Clean the hub mounting surface thoroughly. Step 3 — Verify the new rim PCD and center bore match the tractor hub before installation. Step 4 — Mount the 750-16 tire onto the rim using proper tire mounting equipment. Step 5 — Position the wheel onto the hub, aligning bolt holes. Step 6 — Install and hand-tighten all 6 lug nuts, then torque in a cross-pattern to specification. Step 7 — Adjust tire pressure to the tractor manufacturer recommended PSI. Step 8 — For adjustable-width rims, verify the track width setting matches the opposite wheel. ISO9001 certified. 1-year warranty. Kingstream OEM.
SYMPTOMS OF RIM FAILURE: Cracks radiating from bolt holes, bent rim from impact with rocks or stumps, rust perforation causing air leaks on tubeless setups, stripped bolt holes, and wheel vibration during road travel. For farm tractor fleet wheel maintenance, contact us for competitive pricing. Kingstream OEM.
Technical Specifications
| Parameter | Value |
|---|---|
| Rim Size | 5.5F × 16 |
| Tire Size | 750-16 |
| Bolt Pattern | 6-Hole (Multiple PCD Options) |
| Material | Steel, 8mm Disc Thickness |
| Finish | White / Gray Stoving Varnish |
| Weight | 20 kg |
| Certification | ISO9001 |
1-year warranty. Kingstream OEM. Contact us.
Full Category Coverage
One supplier for all forklift systems — engine, hydraulic, electrical, mast, brake, undercarriage. No need to juggle multiple vendors.
No Minimum Order
Trial orders welcome. Single-piece to bulk supply. You test first, scale later. We treat every order seriously.
Three Quality Choices
Original, OEM, or Aftermarket. You decide based on budget and application. We don't upsell — you control cost and performance.
Direct 1-on-1 Communication
You talk to the sourcing decision maker. No sales reps, no forwarding. Faster answers, clearer quotes, real accountability.
Mixed Order Consolidation
Combine different parts in one shipment. Save on freight. We handle the picking, packing, and export documentation.
After-Sale Warranty
Manufacturing defects covered. Free replacement or credit arranged quickly. Your trust is worth more than any single transaction.
Same part, different brand numbers. This cross-reference table helps you confirm compatibility across multiple forklift brands. If your brand or part number is not listed, send it to us — we will match it.
| Brand | OEM Part Number | Notes |
|---|---|---|
| TOYOTA | 47201-23300 | Original |
| KOMATSU | 3EB-30-41200 | Original |
| HELI | 24022-83011 | Original |
| HANGCHA | R240-83011 | Original / OEM |
| LINDE | 0009830123 | OEM |
| HYSTER | H47201-233 | OEM |
| TCM | TCM-47201 | OEM |
| AFTERMARKET | AM-47201 | Cost-effective replacement |
