Factory Direct Sale High Quality HE221W Turbo Industrial Agricultural QSB4 4043949 4043948

Forklift Brake Vacuum Booster for 5-10 Ton Forklifts

This forklift brake vacuum booster is a power-assist device designed for 5-10 ton internal combustion forklifts equipped with vacuum-assisted hydraulic brake systems. The vacuum booster amplifies the mechanical force applied by the driver on the brake pedal, using engine intake manifold vacuum to create a pressure differential across a large-diameter diaphragm, multiplying pedal effort by approximately 4-6 times. This reduces driver fatigue during frequent stop-and-go operations in warehouse and logistics environments.

The booster housing is constructed from heavy-gauge stamped steel with a corrosion-resistant electrocoat finish, assembled with a reinforced double-diaphragm design that provides consistent power assist across the full pedal travel range. The internal reaction disc and valve assembly are precision-calibrated to deliver progressive brake feel. The atmospheric valve draws filtered air through a foam silencer element, and the one-way check valve on the vacuum inlet port prevents vacuum loss during engine shutdown.

Compatible with HELI K50-K70, Hangcha K50-K70, Lonking K Series, and other domestic-brand 5-10 ton forklifts using vacuum-assisted hydraulic drum brake systems. Verify the mounting stud pattern, master cylinder push rod length, and vacuum line fitting size match your existing unit before installation. Replace the vacuum hose and one-way check valve during booster replacement. For compatible master cylinders, wheel cylinders, and brake overhaul kits, visit our Forklift Brake Parts section.

Technical Specifications

• SKU: VACUUM-BOOSTER-5-10T
• Capacity: 5-10 Ton Forklift
• Type: Vacuum-Assisted Double-Diaphragm
• Housing: Steel, Electrocoat Finish
• Vacuum Source: Engine Intake (18+ inHg)
• Includes: Booster, Check Valve, Mounting Gasket

Compatible Forklift Models

Each booster is vacuum-tested for diaphragm integrity and valve function before packaging. Ships with check valve pre-installed, mounting studs protected. 12-month warranty. Contact our team for fleet brake system support.
