Doosan Forklift Clutch Housing D35S-2/D50C-2 BSX0005686 – 3.5-5T Diesel OEM

Doosan Forklift Clutch Housing D35S-2/D50C-2 BSX0005686 — 3.5-5T Diesel Automatic Wave Clutch Cover, OEM

This is the Doosan OEM clutch housing (part number BSX0005686) for Doosan D35S-2 and D50C-2 diesel forklifts in the 3.5 to 5 ton class — the cast iron bell housing that connects the engine block to the automatic transmission on these heavy-duty Korean-manufactured forklifts. The D50C-2 in particular is a 5-ton-capacity machine used in ports, lumber yards, steel mills, and heavy manufacturing where the clutch housing must withstand the torque of a large-displacement diesel engine transmitting power through an automatic transmission with a torque converter — the clutch housing sees not only the static engine torque but also the torque multiplication from the torque converter during stall conditions (when the forklift is pushing against an immovable load while the engine is at full throttle, the torque converter multiplies engine torque by a factor of 2.0-2.5×, transmitting up to double the engine’s rated torque through the clutch housing-to-transmission bolted joint). This is an automatic wave clutch cover replacement — the “wave” designation refers to the wave spring used in the automatic transmission clutch pack, which provides progressive engagement characteristics essential for smooth forklift operation when handling delicate or unstable loads that would shift or tip with jerky transmission engagement.

Doosan OEM brand, new condition, for replace/repair. 15 kg gross weight (40×30×25 cm package). Applicable forklift models: D35S-2 (3.5 ton) and D50C-2 (5.0 ton) diesel forklifts. Model: clutch housing. For diesel forklift applications. When replacing a clutch housing on a D50C-2, always verify the housing-to-engine alignment dowels are present and undamaged — the dowels are what actually align the housing, not the bolts. Bolts provide clamping force; dowels provide position. Missing or damaged dowels must be replaced before installation. The pilot bore in the crankshaft for the torque converter hub must be inspected for wear or scoring — if the torque converter hub pilot has been running in a worn pilot bore, the resulting vibration has likely damaged the housing alignment dowels or elongated the bolt holes. Check all housing bolt holes for elongation — a housing that has been operating with loose bolts will have oval bolt holes that prevent correct alignment even with new bolts torqued to specification. After installation, torque the housing-to-engine and housing-to-transmission bolts to the Doosan factory torque specification in a cross-pattern sequence. Check bolt torque after the first 50 hours of operation.

Compatible with Doosan D35S-2 (3.5T) and D50C-2 (5.0T) diesel forklifts. Browse our clutch housing selection for HELI 2-3T. Visit Doosan Forklift official website.

Technical Specifications

Compatible Models

Doosan OEM. Heavy-duty automatic. Confirm your Doosan model →
