Forklift Motor 48V 3KW – DM430 JU2-H1890-21

Forklift DC Motor DM430 — 48V 3KW JU2-H1890-21 Electric Drive Motor with 19 Teeth for Forklift Trucks & Golf Carts

This forklift DC motor model DM430 (JU2-H1890-21) is a Kingstream OEM 48V 3KW electric drive motor with 19 spline teeth for forklift trucks and electric vehicles. The motor is a compatible replacement for DM430-06, DM430-06A, DM430-06C, DM430-06D, DM430-06G, and JU2-H1890-20-00 through JU2-H1890-23-00 series motors. 2800 RPM rated speed with IE2 efficiency rating. 10A continuous current at 48V. 1-year warranty with 3-month minimum. MOQ 1 piece. Kingstream OEM quality.

Installing the JU2-H1890-21 DM430 motor requires flange mounting the motor to the vehicle chassis or transaxle, engaging the 19-tooth splined motor shaft with the drive axle input coupling, and connecting the motor power cables to the DC motor controller. The 19-tooth spline must match the mating coupling exactly — an incorrect spline count prevents engagement, and forcing a mismatched spline damages both the motor shaft and the coupling. After mounting, verify the motor shaft rotates freely without binding and the mounting bolts are torqued to specification. The 3KW power rating at 48V provides adequate torque for 2-4 passenger golf cart and light electric vehicle applications — the IE2 efficiency rating indicates standard efficiency class, suitable for intermittent duty drive applications. This motor cross-references multiple DM430 variant part numbers (DM430-06 through -06G) and JU2-H1890 series motors, making it a versatile replacement for fleet operators managing mixed equipment. After wiring, verify the motor direction matches the vehicle control input — reversing the field or armature connections reverses rotation. Run the motor at low speed initially to check for abnormal noise, vibration, or sparking at the brushes. 1-year warranty with 3-month minimum covers winding defects and bearing quality.

Technical Specifications

1-year warranty. MOQ 1 piece. Kingstream OEM. For bulk orders, contact us.

The DM430 DC motor is a field-proven drive motor platform with wide cross-compatibility across multiple OEM part numbers. The 48V operating voltage is standard for electric golf carts, light utility vehicles, and some electric forklift platforms. For fleet operators managing mixed electric vehicle equipment, the DM430 offers a single motor solution covering multiple original equipment part numbers — reducing parts inventory complexity. Kingstream OEM quality with 1-year warranty coverage.
