OSPB Orbitrol Steering Unit 3000 PSI – 101s Series
$42.99
OSPB orbitrol steering unit 101s series. 3000 PSI, 100cc displacement, 200 Nm torque, 3/8 inch ports, 30mm shaft, 8kg. Multi-brand forklift hydraulic steering.
OSPB Orbitrol Steering Unit 3000 PSI — 101s Series, 100cc Displacement
The OSPB orbitrol steering unit is a 101s series hydrostatic steering control for forklifts and hydraulic equipment, rated at 3000 PSI with 100cc displacement and 200 Nm continuous torque. This 8 kg steering unit uses a 3/8-inch port size and 30mm shaft diameter, with compact dimensions of 28×15×13 cm and a 3000 RPM maximum rating. The OSPB series is a widely recognized orbitrol standard used across multiple forklift brands and hydraulic steering applications.
This steering unit delivers proportional hydraulic oil flow to the steering cylinder based on steering wheel rotation — the 100cc displacement ensures adequate oil volume for responsive steering on medium to large-capacity forklifts. The 3000 PSI pressure rating provides the force needed for heavy steering loads while the 200 Nm continuous torque rating confirms robust internal construction for sustained industrial operation. Common failure symptoms include: heavy or inconsistent steering (spool wear or gerotor damage), steering creep when driving straight (centering spring failure), external oil leak (shaft seal failure), and delayed wheel response (internal leakage). The unit is not field-rebuildable.
Installation requires depressurizing the steering circuit, labeling and disconnecting hydraulic lines, unbolting from the steering column, and connecting the replacement with correct port configuration using 3/8-inch fittings. Bleed by cycling steering lock-to-lock at idle. For related hydraulic components, browse our Forklift Hydraulic System catalog.
Technical Specifications
| Parameter | Value |
|---|---|
| SKU | SP100327 |
| Type | OSPB Hydrostatic Steering Unit |
| Series | 101s |
| Displacement | 100 cc (3.38 fl.oz) |
| Pressure Rating | 3,000 PSI |
| Continuous Torque | 200 Nm |
| Max RPM | 3,000 RPM |
| Port Size | 3/8 inch |
| Shaft Diameter | 30 mm (1.18 in) |
| Weight | 8 kg |
| Dimensions | 28 × 15 × 13 cm |
Compatible Equipment
| Type | Models |
|---|---|
| Forklift / Hydraulic Equipment | Multi-brand systems requiring OSPB 101s series steering unit, 3/8-inch ports, 30mm shaft |
Each steering unit is packaged for safe transport. Standard freight delivery to major ports. For compatibility or bulk orders, contact our team with your equipment specifications.
Full Category Coverage
One supplier for all forklift systems — engine, hydraulic, electrical, mast, brake, undercarriage. No need to juggle multiple vendors.
No Minimum Order
Trial orders welcome. Single-piece to bulk supply. You test first, scale later. We treat every order seriously.
Three Quality Choices
Original, OEM, or Aftermarket. You decide based on budget and application. We don't upsell — you control cost and performance.
Direct 1-on-1 Communication
You talk to the sourcing decision maker. No sales reps, no forwarding. Faster answers, clearer quotes, real accountability.
Mixed Order Consolidation
Combine different parts in one shipment. Save on freight. We handle the picking, packing, and export documentation.
After-Sale Warranty
Manufacturing defects covered. Free replacement or credit arranged quickly. Your trust is worth more than any single transaction.
Same part, different brand numbers. This cross-reference table helps you confirm compatibility across multiple forklift brands. If your brand or part number is not listed, send it to us — we will match it.
| Brand | OEM Part Number | Notes |
|---|---|---|
| TOYOTA | 47201-23300 | Original |
| KOMATSU | 3EB-30-41200 | Original |
| HELI | 24022-83011 | Original |
| HANGCHA | R240-83011 | Original / OEM |
| LINDE | 0009830123 | OEM |
| HYSTER | H47201-233 | OEM |
| TCM | TCM-47201 | OEM |
| AFTERMARKET | AM-47201 | Cost-effective replacement |
