Forklift Clutch Assembly

Forklift Clutch Assembly： Complete Clutch Kits for Mechanical Transmission Forklifts 2-8 Ton

A forklift clutch assembly is the complete clutch kit — disc, pressure plate, and release bearing — that connects and disconnects engine power to the mechanical transmission. When the clutch wears, the forklift slips under load, produces a burning smell, and eventually cannot move. Kingstream stocks forklift clutch assemblies for HELI, Dalian, Hangcha, and Chinese forklifts from 2 to 8 ton capacity. Every clutch kit is checked for disc spline fit, pressure plate diaphragm height, and release bearing free play.

A complete forklift clutch kit includes three matched components: the friction disc that engages the flywheel, the pressure plate that clamps the disc against the flywheel, and the release bearing that disengages the clutch when the pedal is depressed. Replacing all three as a set is always recommended — a new disc with a worn pressure plate will slip, while a new pressure plate with a worn release bearing will be noisy and may not disengage fully. The JY323 clutch assembly is the standard kit for Dalian forklifts from 5 to 8 tons, while universal 2-3 ton kits cover HELI and Hangcha models in the most common capacity class. A forklift hydraulic clutch assembly uses hydraulic fluid in the release system instead of a mechanical cable linkage.

When replacing a forklift clutch kit, always resurface or replace the flywheel — installing a new disc on a glazed or heat-checked flywheel reduces clutch life by more than half. Check the pilot bearing in the crankshaft and replace if worn. Use an alignment tool to center the disc before tightening the pressure plate bolts. Adjust the clutch pedal free play after installation to ensure the release bearing is not preloaded against the pressure plate fingers.

Popular Clutch Assembly Cross-Reference

Quality Control at Kingstream

Every forklift clutch assembly is checked for disc spline fit, pressure plate diaphragm finger height consistency, and release bearing smooth rotation. Friction material thickness is measured. You receive a clutch kit that engages smoothly and transfers full engine torque without slipping.

Clutch slipping or not disengaging? Send us your model details. Browse our complete transmission parts catalog.
