Customizable Commercial Truck & Forklift Clutch Pressure Plate — Made-to-Spec Replacement

This pressure plate is a customizable clutch cover assembly that bridges the gap between standardized forklift pressure plates (which fit one specific model) and the need for a configurable unit that can be adapted to multiple truck and heavy forklift applications through adjustable bolt patterns, selectable spring rates, and variable mounting dimensions. Unlike the factory-locked pressure plates we supply for specific Heli or TCM models — where the bolt circle, clamp load, and diaphragm finger height are fixed and must match exactly — this unit is designed for workshops and fleet operators who service mixed-brand fleets, older machines with discontinued OEM part numbers, or non-standard drivetrain configurations where the original pressure plate is no longer available and an adaptable replacement is the only viable option. The customizable approach means you specify the outer diameter, mounting bolt PCD, spline hub bore, and spring type, and the unit is configured to match — eliminating the dead-end search for a discontinued OEM number.

The most critical spec to get right on a customizable pressure plate — and the one most commonly misordered — is the diaphragm spring clamp load rating. This is not the same as the clutch disc diameter. A 275mm disc can pair with a pressure plate rated anywhere from 4,500 N to 7,200 N of clamp force depending on whether it’s going into a 2-ton electric forklift or a 5-ton diesel truck. Installing an under-spec pressure plate on a high-torque engine results in clutch slippage the moment the operator attempts a loaded start on an incline; installing an over-spec unit gives you an unnecessarily heavy pedal and accelerated release bearing wear with zero performance benefit. The second critical dimension is diaphragm finger height — the distance from the pressure ring friction surface to the tips of the diaphragm spring fingers. This measurement determines release bearing stroke geometry, and a mismatch here means the clutch either won’t fully disengage (fingers too low, not enough bearing travel) or the bearing constantly rides the fingers (fingers too high, causing bearing seizure within hours). Always measure your existing unit’s finger height and clamp load before ordering a customizable replacement.

Suitable for 2-5 ton diesel forklifts and light/medium commercial trucks from Heli, Hangcha, TCM, Toyota, Komatsu, Isuzu, Hino, and Mitsubishi Fuso where the original pressure plate part number is unavailable or a configurable replacement is preferred. Customizable parameters include outer diameter (250mm-350mm range), bolt circle PCD, spline count, and spring rate. Specify your existing unit’s dimensions when ordering — we match to your specs, not a catalog number. For fixed-spec forklift pressure plates, browse our clutch pressure plate category. For OEM part number lookup, visit Heli official website.

Technical Specifications

• SKU: CLUTCH-PP-CUSTOM
• Key Differentiator: Customizable — bolt pattern, clamp load, finger height, and OD configurable to order. NOT a fixed-spec OEM replacement.
• Available OD Range: 250mm – 350mm
• Spring Type: Diaphragm (Belleville) — Clamp Load Selectable 4,500N – 7,200N
• Material: Cast Iron Cover, Forged Steel Diaphragm Spring, Ground Pressure Ring
• Application: 2-5 Ton Diesel Forklifts & Light Commercial Trucks — Multi-Brand

Compatible Applications (Custom Spec — Verify Dimensions Before Order)

Kingstream customizable pressure plates are built to your specified dimensions with full QC documentation including diaphragm finger height verification, clamp load test report, and dynamic balance certificate. Individually packed in VCI anti-corrosion wrapping and heavy-duty export cartons. 12-month replacement warranty. Contact us with your required OD, bolt PCD, spline count, and engine application for a tailored quotation.
