Linde 48V 100A Genuine Forklift Battery Charger — 711-840Ah

This is a genuine Linde 48-volt 100-ampere industrial battery charger engineered for Linde electric forklifts, designed to charge 711Ah to 840Ah capacity lead-acid traction batteries efficiently and safely. As an OEM Linde charger, it is factory-calibrated to match Linde’s battery management system (BMS) protocols, ensuring optimal charge profiles that maximize battery cycle life while minimizing energy consumption and charge time. The automatic multi-stage charging algorithm includes bulk charge (constant current), absorption charge (constant voltage), and float/trickle maintenance phases, with automatic transition between stages based on real-time battery voltage and temperature monitoring. The charger delivers up to 100A of charging current, enabling a discharged 840Ah battery to reach 80% state of charge within approximately 6-7 hours.

The charger enclosure is constructed from powder-coated heavy-gauge steel with IP54-rated protection against dust and water splashes, suitable for wall-mount or floor-stand installation in warehouse charging stations. The front panel features an intuitive LED status display showing charge progress, fault codes, and battery connection status, along with an emergency stop button and main power switch. Internally, the charger uses high-frequency IGBT-based power conversion technology that achieves over 92% efficiency, reducing electricity costs and heat generation compared to older transformer-based chargers. Safety features include reverse polarity protection, over-temperature shutdown, short-circuit protection, and automatic detection of sulfated or deeply discharged batteries with a recovery/desulfation mode.

Designed specifically for Linde E14 through E50 series electric forklifts using 48V battery systems in the 711-840Ah range, as well as Linde electric pallet trucks and tow tractors with similar battery configurations. The charger connects via the standard Linde battery connector (REMA-type or similar heavy-duty industrial plug) with color-coded positive/negative leads. Before installation, ensure the charger is connected to a dedicated 3-phase AC supply (typically 380-480V, 50/60Hz) with adequate circuit protection. Mount in a well-ventilated area with at least 150mm clearance on all sides for proper cooling airflow. For compatible Linde batteries, battery connectors, and charging cables, visit our Electronic Control Parts catalog. For charger specifications and maintenance schedules, refer to Linde Material Handling official resources.

Technical Specifications

• Voltage: 48V DC (Output)
• Charge Current: 100A Maximum
• Battery Capacity: 711 – 840Ah Compatible
• Input: 3-Phase 380-480V AC, 50/60Hz
• Efficiency: >92% (IGBT High-Frequency)
• Protection: IP54 Enclosure
• Mounting: Wall-Mount or Floor-Stand

Compatible Linde Forklift Models

Each charger is fully bench-tested before shipment: full charge cycle verification on a load bank, insulation resistance testing, output ripple measurement, and safety interlock functional test. The charger ships in a reinforced wooden crate with foam padding and moisture-absorbing desiccant packs. Installation requires a qualified electrician for 3-phase power connection. All Kingstream chargers carry a 12-month warranty against manufacturing defects. For fleet charging station design, battery maintenance programs, or technical assistance with charger selection and compatibility, contact our technical team with your Linde forklift model, battery specifications, and facility electrical details.
