Forklift Adjustable Pressure Control Valve RV-10-33 – 200Bar

Forklift Adjustable Pressure Control Valve RV-10-33: Direct-Operated 200Bar Steel Relief Valve

The RV-10-33 is a direct-operated adjustable pressure control valve rated for 200 bar (250 bar maximum) hydraulic systems. Constructed from steel tube body with VC10-2 cavity mounting, this two-way relief valve allows operators to manually adjust the system pressure relief set point to match specific forklift hydraulic circuit requirements. At just 0.3 kg and 12x3x3 cm, it installs inline or in manifold cavities on forklift pump circuits, tilt cylinders, and attachment hydraulic systems where precise pressure limiting prevents component damage and hydraulic fluid overheating.

With 3/8″ port connections (1/4″ pressure connection) and 40 L/min (10.57 gpm) flow capacity, the RV-10-33 handles the flow rates of 1-5 ton counterbalance forklift hydraulic systems. The direct-operated design means the poppet and spring respond instantly to pressure spikes without pilot circuit delay — critical for attachment circuits like side shifters and fork positioners where rapid pressure fluctuations occur. Operating temperature range of -30 to +120°C covers cold storage to engine bay environments. ISO 9001 and CE certified, each unit undergoes 100% hydraulic function testing before shipment. Backed by a 12-month warranty with after-sales technical support.
