Forklift Speed Limit Valve YY-D28B8-60201Y – CPCD35

Forklift Speed Limit Valve YY-D28B8-60201Y: Hydraulic Speed Governor for CPCD35

The YY-D28B8-60201Y speed governor is a hydraulic flow control valve designed specifically for CPCD35 forklift series mast lowering circuits. Unlike generic flow control valves, this unit is calibrated at the factory to match the specific cylinder bore diameter and oil viscosity requirements of the CPCD35 — delivering consistent, predictable lowering speed across the full 3-3.6 ton load range. The valve body is cast iron with a black coating for corrosion resistance, and the internal spool uses a spring-loaded compensator that automatically adjusts the metering orifice based on return-side back pressure.

A key differentiator from the standard D28B8-60201 is the “Y” suffix designation — indicating reinforced internal springs rated for higher flow volumes associated with the larger lift cylinders on CPCD35 compared to 1-3 ton models. Installing a non-Y variant on a CPCD35 results in noticeably faster lowering speeds under heavy loads, which can lead to load instability and premature brake wear. The valve weighs 0.90 kg and mounts directly on the lift cylinder port block using standard BSPP 3/8″ ports. Installation is directional — the cast-in flow arrow on the valve body must point toward the tank return line.

Common failure symptoms include sudden increase in lowering speed under load (spring fatigue), erratic or pulsing mast descent (spool binding from contaminated oil), and complete loss of lowering control (stuck-open poppet from debris). This part is a direct OEM replacement for the CPCD35 factory-installed governor and is 100% factory pressure tested before shipment.

Need a different tonnage variant? Browse all speed limiting valves or visit HELI official for specifications.
